Revolving doors ASSA ABLOY RD700
ASSA ABLOY RD700 revolving door is a high-performance entrance solution designed for heavy-traffic environments, combining superior capacity, energy efficiency, and safety.
ASSA ABLOY RD700 Revolving Door - high capacity and intelligent performance
The ASSA ABLOY RD700 is a modern revolving door engineered for buildings with intensive pedestrian flow, where reliability, safety, and energy efficiency are essential. Its spacious three-wing design allows smooth and comfortable access for large numbers of visitors, including wheelchair users and people with luggage or shopping carts.
One of the key advantages of this model is its ability to effectively prevent drafts and unwanted air exchange. This helps maintain a stable indoor climate while significantly reducing heating and cooling costs.
The door features a robust modular construction made of durable aluminum profiles combined with laminated safety glazing, ensuring long service life even under demanding conditions. The system is available in multiple diameters and can be customized to meet specific architectural and operational requirements, including rotation direction and finishing options.
Operational safety is ensured by the advanced CDC control system, which continuously monitors performance, performs automatic diagnostics, and logs system events. Integrated contactless safety sensors instantly detect obstacles and stop the door when necessary. In emergency situations such as power failure or fire alarm activation, the door unlocks automatically to allow safe evacuation.
An integrated IoT module enables remote monitoring and maintenance, providing real-time data on door performance and usage patterns. This allows proactive service planning, reduced downtime, and improved operational efficiency.
The ASSA ABLOY RD700 supports multiple operating modes, including automatic, manual, and energy-saving settings, with adjustable rotation speed in compliance with safety standards. A wide range of optional features and accessories makes it a flexible solution for various types of commercial and public buildings.
|
Country of origin
|
Sweden |
|
Number of wings
|
3 |
|
Inside diameter
|
4200 - 6200 mm |
|
Clear passage height
|
2000 - 2600 mm |
|
Canopy height
|
340 - 1250 mm |
|
Clear passage width
|
1991 - 2992 mm |
|
Operating power
|
400 W (30 W at standby) |
|
Operating temperature
|
-20...+50°C |
|
Power supply
|
230 V AC 50 Hz | 100 - 240 V AC, 50 | 60 Hz |
